Technical specifications
Built: 2005
Ship Design: Moss Maritime 929
IMO No: 9298909
Class: ABS
Class Notation: A1, Offshore Supply Vessel, Supply, Tow, AMS, ACCU, DPS-2, FFV 1, UWILD, TCM, PMP+, Ice Class 1C, Fifi 1
Principal dimensions
LOA: 89.3 m
LPP: 78.0 m
Breadth: 20.60 m
Draft Scantling: 7.50 m
Depth Main deck: 9.00 m
Bollard Pull: 203T continuously, 246.6T max (2024)
Free Deck
Free Deck Area: 755 m²
Free Deck Length: 44,1 m
Free Deck Width: 17,4 m
Deck Cargo Capacity: 2100 T
Deck Strength: Aft 15T/m² & Fwd 10T/m²
Equipment
Anchor Handling Drum: 1 x 400 T, capacity 6782 m of 83mm
Towing Drum: 2 x 400 T, capacity 2 x 2877 m of 83mm
Secondary Winch: 1 x 50 T, capacity 2 x 1800 m of 77mm
Chain Lockers: 2 x 264 m33
Capstans: 2 x 15 T
Tugger Winch: 2 x 15 T
Deck Crane: 2 x 5.6 T @ 13.4 m
AHC Winch/A-frame: 20t Evotech AHC winch & 20t A-Frame
Shark Jaws: 2 x 700 T
Stern Roller: 2 x 3m x 3m
Stern Roller SWL: 2 x 685 T
Towing Pins: 2 x 300 T
DP System: GE Seastream DP 2
Reference System: 2 x DGPS Kongsberg, 2 x Radius Interrogator, 3 x Gyrometer Raython, 2 x MRU Seatex
Sensors
1 x MRU Nautica dynamics, 2 x Wind Sensor Obsermet, 1 x Wind Sensor Marinelight
Cabins
Cabin and beds: 21 x 2 man cabins for 42 pax, 14 x Single cabins
